WTE G2500X  - Reactor

Power Consumption

< 15KW, 380V

Water Consumption

Storage about 1 ton， consumption < 100 L/H

Reaction space

About 2.5m3,
about 2 ton/h~5 ton/h (depend on density of waste)

Size of waste

<5cm3 , as smaller as fast

Inlet size

Diameter about 55cm

Outlet size

Diameter about 45 cm

Fuel consumption for system warming

Time of warming up about 1~1.5 hour，

oil consumption is less than 75L.

Fuel type of system

Diesel, or fuel gas,

Max. offgas

About 3500CMH

Pressure

Negative ~0.1bar

Size of system

40 foot container

WTE G2500X - GASTEC

Power consumption

< 15KW, 380V

Water consumption

Storage about 4 ton， consumption < 20L (depend on type of waste)

Distillation capacity

3000 CMH max

Including fuel, water, steam separator

Including fuel gas cleaning with activated carbon filter

Including Sulfide , Chlorine removing function

Including waste water treatment

Online fuel gas monitor for H2, CH4, Sulfide, Chlorine

Including Sulfide removing from oil by catalyst

Including oil purification
