WTE G1000  Integrated Continuous Fast Thermal Decomposition System

Power consumption

< 15KW, 380V

Water consumption

Storage about 3 ton, consumption < 70 L /H

Reaction space

About 1.2m3, process rate about 1 ton/h~2.5 ton/h
(depend on density of waste)

Size of waste

Size of waste: <5cm3, as smaller as fast

Inlet size

Diameter about 40cm

Outlet size

Diameter about 30 cm

Fuel consumption for system warming up

Time of warming up about 1~1.5 hour, oil consumption about 45 L

Type of fuel for warming up

Diesel oil or fuel gas

Max. offgas

Max. 2000CMH

Pressure

Negative ~0.1bar

Size of system

L=18m, W=2.35m, H=2.35m

Distillation capacity

1500 CMH max

Including fuel, water, steam separator

Including fuel gas cleaning with activated carbon filter

Including Sulfide , Chlorine removing function

Including waste water treatment

Online fuel gas monitor for H2, CH4, Sulfide, Chlorine

Including Sulfide removing from oil by catalyst

Including oil purification
